(Collision avoidance system for crane and moving machineries)
The Anti-collision system is a safety device to avoid to collision of two electric overhead travailing cranes working on the same rails. For one pair of cranes two sets of anti-collision system are required. Each set consist of an Emitter/sensor module and a Reflector.
| Product Specification |  | | | |
|---|---|---|---|---|
| Model No.: | ACC03 | ACC10 | ACC15 | ACC102 |
| Supply Voltage | 230 V AC/110 V AC (User Selectable) | 230 V AC/110 V AC (User Selectable) | 230 V AC/110 V AC (User Selectable) | 230 VAC/110 V AC (User Selectable) |
| No. of Set Points | Single | Single | Single | Two set point independently adjustable |
| No. of Output/ Relay | Single Relay / Single Output | Single Relay / Single Output | Single Relay / Single Output | Single Relay / Single Output |
| Contact Rating | 3 Amps (max.) at 220 V AC | 3 Amps (max.) at 220 V AC | 3 Amps (max.) at 220 V AC | 3 Amps (max.) at 220 V AC |
| Dimension | 180mm x 145mm x 55mm | 180mm x 145mm x 55mm | 180mm x 145mm x 55mm | 180mm x 145mm x 55mm |
| Reflector Size | 130mm x 75 mm | 130mm x 75 mm | 130mm x 75 mm | 130mm x 75 mm |
| Housing | Metal Housing | Metal Housing | Metal Housing | Metal Housing |
